CNC Router Machine

Model Name/Number

CR-481

Warranty

1 year

Usage/Application

curving, spindlework = 0 to 180 degree

Power Consumption

15kw

Model

CR - 3

CR - 4.5

CR - 6

X-Y-Z Axis Working Area

1300 X 2500 X 200 mm

1300 X 2500 X 200 mm

1300 X 2500 X 200 mm

X-Y Movement

Rack & Pinion, Gear Drive / Taiwan

Rack & Pinion, Gear Drive / Taiwan

Rack & Pinion, Gear Drive / Taiwan

Z Movement

Ball Screw Drive / Germany

Ball Screw Drive / Germany

Ball Screw Drive / Germany

Guide

Linear 25 mm Square / Taiwan Y- Axis
Linear 20 mm Square / Taiwan X-Z Axi

Linear 25 mm Square / Taiwan Y- Axis
Linear 20 mm Square / Taiwan X-Z Axis

Linear 25 mm Square / Taiwan Y- Axis
Linear 20 mm Square / Taiwan X-Z Axis

Spindle

3 kw (Air Cooling) / HSD Italy

4.5 kw (Air Cooling) / HSD Italy

6 kw (Air Cooling) / HSD Italy

Spindle Speed

24000 rpm

24000 rpm

24000 rpm

Maximum Speed

35,000 mm/min

35,000 mm/min

35,000 mm/min

Maximum Cutting Speed

25,000 mm/min

25,000 mm/min

25,000 mm/min

Drive Motor

Stepper / Servo (Optional)

Stepper / Servo (Optional)

Stepper / Servo (Optional)

Inverter Power

Delta Taiwan 3.7 kw

Delta Taiwan 5.5 kw

Delta Taiwan 7.5 kw

Repositioning Resolution

+-0.02 mm

+-0.02 mm

+-0.02 mm

Command Code

G-Code

G-Code

G-Code

Controls

DSP A11

DSP A11

DSP A11

Computer Interface

USB 2.2

USB 2.2

USB 2.2

Software

Router 8 / France

Router 8 / France

Router 8 / France

Working Voltage

415V, 50 Hz / 3-Phase

415V, 50 Hz/3-Phase

415V, 50 Hz/3-Phase

Machine Size

3120 X 1960 X 1700 mm

3120 X 1960 X 1700 mm

3120 X 1960 X 1700 mm

Weight

1450 kg

1450 kg

1450 kg

Vacuum Pump

5.5 kw Chinese Backer Pump

5.5 kw Chinese Backer Pump

5.5 kw Chinese Backer Pump

Standard Equipment Include

1. Auto Tool Surface sensor
2. Manual Oil lubrication System
3. Dust Hood
4. T-Slot Vacuum Table
5. Regenerative Blower 7.5 kw

1. Auto Tool Surface sensor
2. Manual Oil lubrication System
3. Dust Hood
4. T-Slot Vacuum Table
5. Regenerative Blower 7.5 kw

1. Auto Tool Surface sensor
2. Manual Oil lubrication System
3. Dust Hood
4. T-Slot Vacuum Table
5. Regenerative Blower 7.5 kw
