Four Side Moulder Machine

Model

SM - 412

SM - 416

Working width

25-120 mm

25-160 mm

Working thickness

8-110 mm

8-120 mm

Over all platform length

1250 mm

1800 mm

Feeding speed

5-36 m/min

5-36 m/min

Spindle diameter

40 mm

40 mm

Spindle speed

6000 r/min

6000 r/min

Pressure

0.6 Mpa

0.6 Mpa

First bottom spindle

3 kw/ 4 hp

4 kw/ 5.5 hp

First top spindle

4 kw/5.5 hp

5.5 kw/7 hp

Right side spindle

3 kw/4 hp

4 kw/5.5 hp

Left side spindle

3 kw/4 hp

4 kw/4 hp

Feed beam rise & fall

0.55 kw/0.75 hp

0.75 kw/1 hp

Feeding

2.2 kw/3 hp

3 kw/4 hp

Total motor power

15.95 kw/20 hp

21.25 kw/40 hp

Right side spindle

Dia. 125-160 mm

Dia. 125-160 mm

Left side spindle

Dia. 125-160 mm

Dia. 125-160 mm

First bottom spindle

Dia. 125 mm

Dia. 125 mm

First top spindle

Dia. 125-160 mm

Dia. 125-160 mm

Second top spindle

-

Dia. 125-160 mm

Second bottom spindle

Dia. 125-160 mm

Dia. 125-160 mm

Feeding wheel diameter

Dia. 120 mm

Dia. 120 mm

Dust absorption tube diameter

Dia. 120 mm

Dia. 125 mm

Over all dimensions

2500 x 1450 x 1610 mm

3000 x 1500 x 1650 mm

Voltage

415V, 50 Hz/3-Phase

415V, 50 Hz/3-Phase
