Semi - Automatic Finger Jointing Line

CM - FJL-150

Infeed Length

150 - 850 mm

Shaping Thickness

20 - 150 mm

Maximum Working Width of Shaper Working Table

450 mm

Pressing Thickness

20 - 80 mm

Pressing Width

30 - 150 mm

Shaper Spindle Diameter

50 mm

Shaper Spindle Speed

5800 rpm

Hogger Spindle Diameter

30 mm

Hogger Spindle Speed

2840 rpm

Maximum Pressing Length

2500 mm

Maximum Thrust Force

3000 kg

Shaper Spindle Power

11 kwx 2

Hogger Power

4 kw x 2

Scoring Saw Power

0.75 kw x 3

Hydraulic System Power For Press

4 kw

Saw Blade Power For Press

2.2 kw

Total Conveyor Power For Press

1.1 kw x 2 + 0.75 kw

Total Power For Belt Conveyor

0.75 kw

Total Power For Roller Conveyor

0.75 kw

Total Motor Power

42.9 kw

Air Pressure

6 - 8 Bar

Wind Measure of Dust Collector

9000 m3/h

Fixing Dimensions

8000 x 5000 mm

Voltage

415V, 50Hz/ 3-Phase
