Spindle Moulder

Brand

celmac

Model Name/Number

SM-625-TS / SM-735-TS

Weight

776kgs

Spindle Speed

3000/4500/6000/10000rpm

Fix Table Size

1220X330mm

Usage/Application

Wood Moulding

Power

10HP

Automation Grade

Semi-automatic

Model

SM - 625-TS

SM-735-TS

Spindle Diameter

3/4 inch, 1 inch, 1-1/4 inch, 30 mm, 35 mm

1-1/4 inch, 30 mm, 35 mm, 40 mm

Spindle Speed

3000 / 4500 / 6000 / 10000 rpm

3000 / 4500 / 6000 / 10000 rpm

Taper of Spindle

MK5

MK5

Spindle motor

7.5 hp , 3-Phase

10 hp

Spindle Travel

5inch (130mm)

180 mm

Tilting Angle

-5 - 90 - + 45 Degree

-5 - 90  + 45 Degree

Maximum Table Insert Diameter

210 mm (8-1/4 inch)

366 mm (13-1/4 inch)

Table Size

1050 x 800 mm

1 1220x930 mm

Table Height

900 mm (35-1/2 inch)

900 mm (35-1/2 inch)

Sliding Table Size

1050 x 250 mm

1220 x 330 mm

Sliding Table Travel

970 mm (38 inch)

1170 mm (46 inch)

Over All Dimensions

1220 x 1170 x 1270 mm

1070 x 1070 x 1270 mm

Weight

576 kg

776 kg

Voltage

415V, 50Hz/ 3-Phase

415V, 50Hz/ 3-Phase
